1SAP130300R0271 Supports Ethernet communication

Product features
Redundancy technology: supports the DT Ring protocol family (self-healing time<50ms) and MSTP
Multicast protocol: supports IGMP Snooping, GMRP, and static multicast
Network partitioning: Supports VLAN and PVLAN
Service quality: Supports QoS
Bandwidth management: supports port aggregation, port speed limiting, and broadcast storm suppression
Network management monitoring: supports CLI, Telnet, WEB management methods, Kyvision centralized management, SNMPv1/v2/v3,RMON,LLDP,SNTP,DHCP
Network security: supports DT Psec, SSH, SSL, ACL
Device management: supports FTP upgrades
Equipment maintenance: Supports port mirroring
Alarm output: Supports IP/MAC conflict, power, port, and ring alarms
Special features: Supports Link Check and loop locking
Product specifications
technical parameter
Standard: IEEE 802.3i, IEEE 802.3u,IEEE 802.3x,IEEE 802.1p,IEEE802.1Q,IEEE 802.1s
Protocol: DT Ring, DT-Ring+,DT-VLAN,MSTP;IGMP snooping,GMRP;
VLAN,PVLAN;Telnet,HTTP,HTTPS,SNMPv1/v2/v3,RMON,
LLDP,SNTP,DHCP server;DT-Psec,SSH,SSL,ACL;FTP;ARP,QoS
interface
100Mbps optical port: PECL level, pin output
100Mbps electrical port: 10/100Base-T (X), pin output
Console port: RS232, pin output
button
Reset: System reset
Exchange attributes
Priority queue: 4 VLANs: 256
VLAN ID：1～4094 Number of multicast groups: 256
MAC Table: 8K Packet Buffer: 2Mbit
Packet forwarding rate: 0.9Mpps Exchange latency:<5 μ s

1SAP130300R0271 Supports Ethernet communication

system parameter
processor
Intel Core i3 8100T (quad core quad threaded, 3.1 GHz main frequency)
Intel Core i5 8500T (Six Core Six Thread, Main Frequency 2.1 GHz, Rui Frequency Up to 3.5 GHz)
Intel Core i7 8700T (six core twelve thread, main frequency 2.4 GHz, Rui frequency up to 4.0 GHz)
Chipset
Intel H310
Memory
Supports 2 DDR4 2133/2400 SODIMM memory slots, up to 32GB
BIOS
AMI EFI BIOS
Display chip
Integrated with Intel ® Ultra Core Graphics Card 630
Display interface
1 VGA display interface and 2 HDMI high-definition display interfaces (supporting synchronous/asynchronous dual display)
Front panel I/O ports
6 USB 2.0 interfaces, 2 COM ports, and 1 metal switch
Rear board I/O ports
2 USB 3.0 interfaces, 2 Gigabit Ethernet ports, 1 VGA interface, 2 HDMI interfaces, 1 Mic, and 1 Line Out
4 COM ports (COM2 optional RS232/RS422/485), 1 DC power supply interface
Expansion interface
Supports 1 M.2 2280 slot (compatible with PCIE and SATA signals)
Supports 1 MINI PCIE slot (supports WIFI/Bluetooth)
Scalable interface: GPIO (4 in and 4 out)
network interface
Two RTL8111H Gigabit Ethernet interfaces
Storage interface
Supports 1 M.2 2280 slot, comes standard with 1 2.5-inch hard drive slot (optional 2 2.5-inch hard drive slots)
input voltage
Supports DC 12-19V input (optional DC 9-36V wide voltage input)
Other functions
Power on, timed power on, network wake-up, PXE startup, watchdog (level 0-255)
Structural parameters
Case color
Titanium gray (color can be customized freely)
Chassis material
High quality all aluminum alloy with hard anodized surface
Product size
230 * 219 * 84 mm [excluding wall bracket]
Overall weight
4.0 kg [excluding wall mount]

Contact information:+86 15359213550
