TSXP572823M  Manage relays

This relay has 5 A-phase CT secondary. The HI control power supply is 90-300 VDC and 70265 VAC, with a frequency of 48-62 Hz. The analog output on this relay is 4 to 20 mA. This relay has a basic display. It is unsafe to contact the relay contacts when the relay is powered on. If low voltage accessible applications require output relay contacts, it is the responsibility of the customer to ensure appropriate insulation levels. The rated current of the fuse is 2.5A, the fuse model is 5x20mm HRC SLO-BLO Littelfuse, and the fuse model is 215-02.5.

The ordering code for this series provides users with detailed information about the component. 489 indicates which series this part comes from. The next two digits are the phase current inputs, which are P1 (1A phase CT secondary side) or P5 (5A phase CT secondary side). The next two digits are the control power supply, which are LO (20-60 VDC and 20-48 VAC, 48-62 Hz) or HI (90-300 VDC and 70-265 VAC, 48-62 Hz). The next two or three digits are analog outputs, which are A1 (0 to 1 mA analog output) or A20 (4 to 20 mA analog output). The next one is the display screen, which can be blank (basic display screen), E (enhanced display screen with larger LCD), or T (enhanced display screen with Ethernet 10Base-T). The next one is protection against harsh environments, where H is a chemical environment conformal coating.

Our products are widely used in CNC mechanical metallurgy, petroleum and natural gas, and petrochemical industries,
Chemical industry, paper and printing, textile printing and dyeing, machinery, electronic manufacturing, automobile manufacturing,
Plastic machinery, electricity, water conservancy, water treatment/environmental protection, municipal engineering, boiler heating, energy, power transmission and distribution.
The quoted price is not the actual price. Please contact the shopkeeper before placing the order to confirm the price and delivery time!!!

Contact information:+86 15359213550
